AI Agent Architecture: Types, Key Components, and Implementation on Vertex AI

"While everyone argues about how to write the perfect prompt, we are building infrastructure that generates revenue. What is the difference between a chatbot and an agent? It is like the difference between a calculator and a chief accountant. One just presses buttons; the other makes decisions."
— Founder of ASCN.AI

• Agent ≠ Chatbot: A bot just chats. An agent actually changes something in the external world (CRM, database) following the "See — Think — Act" cycle.
• When an agent is NOT needed: If the task can be solved with a simple `if/else` script with no variations. Do not overcomplicate it.
• 2025 Tech Stack: Use LangChain for quick prototypes. Vertex AI Agent Builder is for serious business (security and scale).
• Real-world case: Our ASCN.AI trading agent saved 80% of client funds when the Falcon Finance token crashed. The algorithm simply executed while people panicked.

In 2025, the term AI agent architecture has finally stopped being science fiction. Agents have become the working standard for businesses that want to grow rather than drown in hiring. Honestly, you are probably not reading this for theory. You are tired of "toy" solutions that look great in demos but break in real combat. You need a system that works while you sleep.

AI agent architecture is, roughly speaking, the skeleton of an autonomous program. It can "see" what is happening around it, make plans, and achieve goals without your minute-by-minute control. A script is a linear command. An agent uses an LLM (large language model) as its brain. It checks memory, selects a tool, and decides on its own.

Below, we will examine how these systems are structured internally. I will provide a framework: you can use it to build agents for sales, complex analytics, or trading. We will compare LangChain and Vertex AI approaches. And, of course, we will cover the common pitfalls that burn budgets and nerves.

What is an AI agent and how does it differ from an LLM chat

An AI agent is a system where the LLM serves as the intelligent core, equipped with “hands” (tools) and “memory” (context). While a chatbot simply generates text in response to a question, an agent executes a task. The result is what matters.

A chatbot outputs a message in a dialogue window. An agent changes the state of the external world: it writes a record to a CRM, initiates a payment, or sends a file to a colleague. The difference is fundamental.

Generative AI produces content. Agentic AI delivers completed work. For example, a chatbot can draft an email. An agent, however, will find the client in the database, personalize the email, send it, log the response in the CRM, and remind you to call in two days. Feel the scale?

Here is a table that settles the debate.

We had a project with a major crypto startup. Funny story. The team tried to replace support with a standard GPT-4-based chatbot. Users were simply furious. The bot politely apologized but did not solve the problem. When we implemented an agent with access to the ticketing system, satisfaction levels soared instantly. AI agents for business truly change the rules: our agent opened tickets on its own, assigned them to the right specialists, and monitored deadlines.

The key difference in **ai agents definition architecture** is simple: an agent’s architecture always includes the “Perception — Thought — Action” loop. Here, the model is just a processor for thinking. Without the other components, it is merely a very expensive typewriter.

But there is a nuance. Architecture requires clear boundaries. If you give the model too much freedom without validation tools, you will get hallucinations in production. In business, this is no joke, especially when finances or documents are at stake.

Anatomy of an AI Agent: Basic Architectural Components

To prevent the system from collapsing on day one, you cannot assemble it from random pieces of code. Strict modularity is required. Every component must be in its place. Violate this rule, and the agent will start lagging or making costly mistakes.

Perception Module: How the Agent “Sees” Input Data

The perception module is the “sensory organs.” It is responsible for receiving signals. This is not just text from a chat. It includes webhooks, PDF files, sensor readings, or cells in Google Sheets. The agent must be able to digest this incoming chaos.

In simple cases, this is just text. In complex ones, it is a multimodal stream. The agent scans a document, sees a decline on a graph, reads the figures, and understands the context. This requires vision models and parsers.

In crypto trading, perception operates at speeds inaccessible to humans. An ASCN.AI agent monitors exchange order books in real time. It sees not just the price, but the volume of limit orders, the spread, and market depth. This is raw noise that needs to be turned into situational awareness.

If the perception module is configured incorrectly, the agent will react to noise. For example, it might mistake a random price spike for a trend and open a position. Therefore, filters are always placed at the input. We use threshold values and confirm data from multiple sources.

Memory and Context: Difference Between Short-Term and Long-Term Storage

Agent memory is divided into two types, and this matters. Short-term memory stores the current dialogue or the status of a specific task. Long-term memory preserves experience, user knowledge, and interaction history. Without long-term memory, the agent is reborn from scratch every time. Like a child.

Short-term memory is limited by the model’s context window. If a task is long, the agent forgets the beginning. That is why we use summarization techniques. Intermediate results are saved so that gigabytes of logs do not need to be carried into every request.

Long-term memory is usually implemented via vector databases. This allows the agent to search for similar cases from the past. You ask about a March report. The agent finds templates from previous years in the database and the style in which you are used to receiving them. Implementation of database automation is a critical stage here.

In business, this is critical for personalization. Clients do not want to explain their preferences hundreds of times. The agent must remember that you prefer concise summaries in the morning and detailed analyses on Fridays. In ASCN.AI, we configure profiles that agents use as context.

Planning and Decision-Making (Planning): ReAct Pattern Breakdown

Planning is the brain of the operation. The model breaks a large goal into subtasks. Here, the ReAct (Reason + Act) pattern works. Creating an AI agent usually starts with configuring this very pattern. The agent reasons about what needs to be done, performs an action, looks at the result, and decides what to do next.

This cycle runs until the task is solved. If the agent gets stuck, it can try a different approach. This is called iterative planning. In complex scenarios, Tree of Thoughts is used to calculate options in advance.

Real-world Example: The Falcon Finance token crash in 2025. The market dropped by 15% in one minute.

Action: Our analytical agent received data on a large holder’s sale. The system assessed the risk of panic. The agent decided to lock in part of the position and move funds into stablecoins without waiting for a human. Full ASCN.AI case study on the Falcon Finance drop.

Result: Clients preserved 80% of their capital while retail investors read panic posts on Telegram.

Disclaimer: Cryptocurrency trading examples are for informational purposes only and do not constitute financial advice. Past performance does not guarantee future results.

Planning also includes resource checks. An ASCN Agent will not start sending a thousand emails if it has run out of API credits. It must be able to stop and ask for help.

Execution Tools (Actions/Tools): API, code, web browsing

Tools are the agent’s hands. The model itself cannot act in the physical world. It must call a function. The toolset defines capabilities. A model without a calculator will make numerical errors; without a browser, it will miss news. In Vertex AI, we connect Google Sheets and CRM systems to handle routine tasks.

In Vertex AI, tools are described via JSON schemas. The agent sees the description and understands when and how to call the function. This allows us to connect agents to Google Sheets or messengers for full-scale operation.

It is important to restrict access rights. The principle of least privilege applies here as well. If an agent only needs to read the database, do not grant it deletion rights.

Example tool schema for Vertex AI:

{
  "name": "get_stock_price",
  "description": "Get current stock price",
  "parameters": {
    "type": "object",
    "properties": {
      "symbol": {"type": "string", "description": "Stock ticker"}
    },
    "required": ["symbol"]
  }
}

Unlike LangChain, you do not need to write complex wrappers manually. In Vertex AI, you describe the tool in JSON, and the model understands the calling logic itself.

AI Agent Architecture Types: From Reactive to Multi-Agent

The choice depends on the task. There is no need to use excessive force for simple problems. Reactive schemes are sufficient for notifications. Complex analytics require cognitive agents. For scale, use a swarm.

Reactive Architecture (Simple Agents): Stimulus -> Response

The simplest type. The agent does not store state or build plans. It reacts to input based on a strict rule. If A, then B. Fast and inexpensive.

Such agents are good for monitoring. For example, tracking prices and sending alerts. Or answering frequent questions based on a knowledge base.

Case study: Earnings from flash crash (October 11).

Situation: Market flash crash on October 11. The agent detected an anomaly. Arbitrage was triggered. The system bought the asset where it had dropped and sold it where the price was still holding.

Result: Profit generated in seconds. A human wouldn’t even have time to press the button.

Speed is critical here. Reactive agents don’t think. They execute logic. In trading, this is the only viable approach.

Deliberative (Cognitive/BDI) Architecture: Beliefs, Desires, Intentions

Here, the agent has “beliefs” (worldview), “desires” (goals), and “intentions” (plans). It adapts its behavior based on context. Almost human-like.

Such agents use planners. They decompose tasks. Goal: “Increase sales.” The agent decides on its own: first analyze the funnel, then scripts, then training.

BDI requires resources. The model maintains many variables. However, it handles uncertainty well. If one approach fails, it tries another.

We use this for complex processes. A marketing agent independently decides which creative to launch based on current conversion rates. It tests hypotheses and cuts what doesn’t work.

Multi-Agent Systems (MAS)

When a single model isn’t enough, you deploy a swarm. A group of agents that communicate. Each has a role: one searches, another writes, a third critiques.

The Orchestrator Role and Agent Hierarchy

A complex system needs a “manager.” The orchestrator distributes tasks. It receives requests and delegates them.

Hierarchy enables scalability. You can add an agent for a new niche without rewriting the core. The orchestrator simply assigns it tasks.

At ASCN.AI, we automate end-to-end processes this way. One agent collects leads, another qualifies them, a third handles negotiations. Context is shared via a common database.

Collaboration Scenarios (Swarm Intelligence)

Agents can work in parallel. Ten agents analyze news simultaneously and produce a summary. Or they write code modules and then assemble them. Collaboration improves reliability: one agent’s error is noticed by others.

Development Toolkit: LangChain vs Vertex AI

The debate is endless. Open-source frameworks or cloud platforms? The truth lies somewhere in between. It depends on resources and requirements. Platform Comparison often shows that the choice depends on maturity.

Open-Source Solutions (LangChain, AutoGen, AutoGPT): Benefits of Customization Flexibility

LangChain has become the standard for prototypes. It offers immense flexibility. You can assemble any complex system from modular blocks. The community releases new tools daily.

The advantage is full control over code and self-hosting. The downside is the need for ongoing support. Updates can break compatibility, requiring you to monitor dependencies closely.

Microsoft’s AutoGen excels at multi-agent workflows. AutoGPT aims for full autonomy but often gets stuck in loops. For production use, they require strict constraints.

We use LangChain for experiments because it is fast. However, for clients requiring 24/7 stability, we look toward cloud platforms.

Cloud-Based Platform Solutions: Overview of Vertex AI Agent Builder

Google provides ready-made infrastructure. Vertex AI Agent Builder allows you to build agents without deep coding expertise, lowering the entry barrier.

Key advantages: If you operate within Google Cloud, integration is seamless. Data flows from BigQuery and documents from Drive without writing custom connectors.

Security: Enterprise-grade. Access is managed via IAM. Auditing is automatic. This is a decisive factor for banks.

Corporate data and RAG out of the box: RAG (Retrieval-Augmented Generation) is configured by default. Upload your documents, and the agent is ready to answer. No need to manually set up vectorization. This saves weeks. In business, time is money. While you tweak your own RAG, competitors have already launched an agent on Vertex.

Detailed Architecture of Vertex AI Agent: Components and Workflow

Let’s examine the mechanics inside Google Cloud. This helps avoid mistakes. Vertex AI Agent is not a black box if you look closely.

Vertex AI Agent Components

The system is modular. You can enable or disable components as needed.

Planner: In Vertex, it is advanced. It accounts for tools and limits. It generates a plan in JSON format. There are “single-step” or “multi-step” modes. For complex tasks, I enable the latter.

Memory Layer: Memory is handled via Datastore. Chat history is saved automatically. You can configure the retention period. For long-term storage, vector databases are connected via Matching Engine.

Workflow diagram

1. User sends a request.
2. System classifies intent.
3. Scheduler builds the chain.
4. Agent calls tools (in parallel or sequentially).
5. Results are compiled into a response.
6. Log is written to memory.

The cycle is optimized for low latency. Google uses its TPUs. This is critical for real-time performance.

Comparison table: How to choose architecture and technology stack

To avoid confusion, we have summarized the options. Focus on your task.

Framework choice depends on the team. No strong developers? Choose no-code or cloud solutions. Have a team? Build the core with LangChain.

Best practices are simple: start small.

Checklist: Agent or script?

Before starting, answer honestly:

• Can the logic be described via if/else? → Use a script.
• Need access to 3+ different APIs without a rigid script? → Use an Agent.
• Is a 5% error rate acceptable? → If not, add Human-in-the-loop (human oversight).
• Can the process be mapped without branching? → Avoid agents; use a rigid workflow instead.

Practice: Typical scenarios and implementation pitfalls

Theory without practice is dead. See where it works and where it breaks.

Industry-specific use cases

In e-commerce, agents handle returns and delivery statuses. They connect to warehouse systems. Customers receive instant responses.

In DevOps, agents monitor logs. If a server crashes, the agent restarts the service and writes a report. This reduces downtime.

In finance — initial scoring. Agents gather data and prepare dossiers for managers. Loans are issued faster.

We see growing demand in marketing. Agents write posts, reply to comments, and manage leads. This frees up people for creative work.

Critical design mistakes

Many make common mistakes. Avoid them.

Why "Prompt + Database" is not an agent

Simply connecting a database is not enough. You need error-handling logic. If the database contains garbage, the agent will output garbage. A validation layer is required. The agent must be able to say "I don't know."

Lack of "Guardrails" against hallucinations

Hallucinations are dangerous. An agent must not promise 90% discounts.

Guardrails are necessary. Input and output filters. Regular expressions, list checks, amount limits. At ASCN.AI, we configure strict rules for financial operations.

"Autonomy without control leads to disaster. I have seen projects where an agent spammed because the success metric was flawed. Safeguards are mandatory."
— Senior AI Architect, ASCN.AI

Incorrect assessment of effectiveness (Evaluation Metrics)

Do not measure success by the number of messages. Focus on outcomes. How many tickets were closed without human involvement? How much revenue was generated? Run an A/B test: agent versus humans.

FAQ: AI Agent Architecture

Answers to frequently asked questions.

Is Python required to create an agent in Vertex AI?
No, you can use the console. However, scripts are useful for complex logic.

What is the difference between a Chain in LangChain and an Agent?
A Chain is a sequence of steps. An Agent decides which steps to take on its own. It has a feedback loop.

How much do agents on Google Cloud cost?
It depends on tokens. Tens of dollars are enough to start. Enterprise solutions start from thousands.

Agent or chatbot: which to choose?
For simple responses — a bot. For performing actions (API calls, updates) — an agent.

Is it difficult to program agents?
Basic skills are enough to start. Deep configuration requires ML knowledge. Learn about pricing for implementation.

The Future of Agents: From LLM to AGI (Trends)

We are moving towards autonomous systems. Agents will become less dependent on prompts. They will adapt without full retraining.

Multimodality will become the norm. The agent will watch video from cameras and listen to voice. A new era in robotics.

Integration with the physical world will strengthen. Control of smart homes, cars, and warehouses. See the forecast: AI and Bitcoin in 2025.

At ASCN.AI, we are preparing for this. The platform already supports complex scenarios. The best products are born here. We are ready to offer you turnkey automation.

Follow our progress. We are building an ecosystem that will transform the market.
